| Frequency Response |
20Hz~50kHz (Attenuation < 0.2dB) |
| DAC Chip |
CS43198; Main control chip (single-chip microcomputer): GD32F303RET6 |
| Output power |
SE power output 1: L+R≥520mW +520mW (32Ω, THD+N < 1%) (32Ω/single-ended/high gain); SE power output 2: L+R260mW+60mW (300Ω, THD+N < 1%) (300Ω/single-ended/high gain); BAL power output 1: L+R≥1400mW+1400mW (32Ω, THD+N < 1%) (32Ω/balanced/high gain); BAL power output 2: L+R>250mW+250mW (300Ω, THD+N < 1%) (300Ω/ balanced/high gain) |
| Output Impedance |
PO < 1.20 (320 load); BAL < 2.40 (329 load) |
| THD+N |
LO < 0.00035% (1kHz/10kΩ) |
| Supported Formats |
384kHz/32bit PCM, DSD256 |
| SNR |
≥123dB (A-weighted) |
